Driver LC 50W 350–1050mA flexC lp EXC excite series SELV Product description Constant current LED driver for luminaire installation For luminaires of protection class I and protection class II Adjustable output current between 350 and 1,050 mA via ready2mains Programmer or I-SELECT 2 plugs Max. output power 50 W Up to 90 % efficiency Nominal lifetime up to 100,000 h 5 years guarantee Housing properties Low profile metal casing with white cover Type of protection IP20 Interfaces ready2mains (configuration via mains) Terminal blocks: 0° push terminals Functions Adjustable output current in 1-mA-steps (ready2mains, I-SELECT 2) Protective features (overtemperature, short-circuit, overload, no-load, input voltage range) Suitable for emergency escape lighting systems acc. to EN 50172 Benefits Application-oriented operating window for maximum compatibility Best energy savings due to high efficiency Flexible configuration via ready2mains and I-SELECT 2 Reliability proven by lifetime up to 100,000 h and 5 years guarantee Typical applications For linear/area lighting in office applications

Read more less

Product family features Line frequency: 0 Hz | 50 Hz | 60 Hz Versatile scope of application due to output power range of up to 120 W Supply voltage: 220…240 V Available with output current range: up to 750 mA Non-isolated drivers Product family benefits Flexible current setting (LEDset2) Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate) High quality of light thanks to low output ripple current Very high efficiency Fulfill safety requirement due to overload, overtemperature, Hot Plug protection Areas of application Linear lighting for office, education, industry, storage areas and retail Installation in emergency lighting systems according to IEC 61347-2-13, appendix J Suitable for installation in emergency lighting systems according to EN 60598-2-22 Suitable for luminaires of protection class I Ecodesign regulation information: Intended for use with LED modules. The forward voltage of the LED light source shall be within the defined operating window of the control gear in all operating conditions including dimming if applicable. Separate control gear and light sources must be disposed of at certified disposal companies in accordance with Directive 2012/19/EU (WEEE) in the EU and with Waste Electrical and Electronic Equipment (WEEE) Regulations 2013 in the UK. For this purpose, collection points for recycling centres and take-back systems (CRSO) are available from retailers or private disposal companies, which accept separate control gear and light sources free of charge. In this way, raw materials are conserved and materials are recycled. Find technical data and additional assets in our datasheet Product Datasheet

Read more less

Constant Voltage Design0-10V DimmableProtections: Short circuit/ Over Voltage/ OverloadOther features:Universal AC input/ Full rangeIP66 design for indoor or outdoor installationsBuilt-in PFC functionCooling by free air convectionOver 83% efficiency3 years warrantyMore Information Manufacturer Ecopac Power Output Wattage (W) 100 Output Voltage 24V Dimmable (Type) 0-10V Dimensions 230x 68.5x 44 EMC Standards Compliance to EN55015, EN61000-3-2 (>50% load) Compliance to EN61000-4-2,3,4,5,6,11 EN61547 A light industry level Input Voltage 100-265VAC Safety Standards EN61347-2-13, IP66 Output Voltage Options Single Working Temperature -40~+60°C PDF Datasheet ELED-100 0~10V Series.pdf

Read more less

Gen 3 will be sent out   Product family benefits Intelligent power matching thanks to Smart power supply Slim form factor for mounting on the cove or in linear luminaires No stroboscopic effect thanks to patented high PWM frequency management (> 2 kHz) Suitable for installation in emergency lighting systems according to EN 60598-2-22 Available as single-channel or multi-channel with DT6 and DT8 in one device DALI message detection "LED Module failure" IP rating: IP20 Areas of application Cove lighting, wall washer, corridor, handrail, luminous ceilings Suitable for use in luminaires of protection class I and II Equipment / Accessories Suitable for 24 V LED modules 4062172274326 Data sheet

Read more less

obsolete ,  please  order the below . Which is the 100W variant     https://www.easy-controlgear.com/products/eled-100-12t-ecopac-constant-voltage-led-driver-eled-100-12t-100w-12v?_pos=1&_sid=6421e0f7f&_ss=r   Constant voltage Triac/ Mains dimming Suitable for leading/ trailing edge Protections: Short circuit/ Over voltage   Other features: Built-in active PFC funtion (PF>0.95) Cooling by free air convection IP66 Rated Design Fully isolated, delivering up to 80W of powerMore Information Manufacturer Ecopac Power Output Wattage (W) 80 Output Voltage 12V Dimmable (Type) Triac Leading edge & Trailing edge Dimensions 200x 68x 45 EMC Standards Compliance to EN55015, EN61000-3-2 (?50% load), EN55015, EN61000-4-2, 3, 4, 5, 6, 8, 11, EN61547, light industry level Input Voltage 175~265VAC Safety Standards EN-60950-1 Output Voltage Options Single Working Temperature -40°C ~ +60°C PDF Datasheet ELED-80-T.pdf

Read more less

Product description NEW: lumDATA (DALI-2 part ext. 251, 252 and 253) Dimmable built-in constant current LED Driver Dimming range 1 to 100 % For luminaires of protection class I and protection class II Output current adjustable between 150 – 700 mA via ready2mains Programmer, I-SELECT 2 plugs or DALI Max. output power 35 W Up to 88 % efficiency Power input on stand-by < 0.2 W Nominal lifetime up to 100,000 h 5 years guarantee Housing properties Low profile metal casing with white cover Type of protection IP20 Interfaces one4all (DALI-2 DT 6, DSI, switchDIM, corridorFUNCTION) ready2mains (configuration and dimming via mains) Terminal blocks: 0° push terminals Functions Adjustable output current in 1-mA-steps (DALI, ready2mains, I-SELECT 2) Fulfills DALI-2 parts: 251 (Luminaire data), 252 (Energy reporting) and 253 (Diagnostics & Maintenance) Constant light output function (CLO) Power-up fading at AC Configurable via ready2mains Switch off the Driver with fade2zero Service monitor to log certain events Protective features (overtemperature, short-circuit, overload, no-load, input voltage range, reduced surge amplification) Intelligent Voltage Guard (overvoltage and undervoltage monitoring) Suitable for emergency escape lighting systems acc. to EN 50172 Benefits Flexible configuration via companionSUITE Application-oriented operating window for maximum compatibility Best energy savings due to low stand-by losses and high efficiency Flexible configuration via DALI, ready2mains and I-SELECT 2 Reliability proven by lifetime up to 100,000 h and 5 years guarantee Typical applications For linear/area lighting in office applications

Read more less

Ecopac ELED-30-24DP2 DALI Dimmable, constant voltage LED driver. Built in short circuit, overload, over current and over temperature protection together with a 3 year warranty make the ELED-30-24DP2 highly reliable.  • Constant voltage/ PWM Output (NFC regulation)• DALI & Push dimming function (0-100%)• AC input: 100-277VAC• Built-in active PFC function• Efficiency up to 83%• Protections: Short circuit/ Over load/Over temperature• Cooling by free air convection• IP20 design for indoor installation.• Suitable for intelligent LED lighting More Information Brand Ecopac Power Output Wattage (W) 30 Output Voltage 24V IP Rating IP20 Non Waterproof Dimmable (Type) DALI, Push Dimming Dimensions 171.5 x 54 x 20 mm EMC Standards Compliance to EN55015, EN61000-3-2, EN61000-3-3 (≥60% load) Input Voltage 100~277VAC Safety Standards EN61347-1, EN61347-2-13, EN62493, IP20 , UL8750 (US) Output Voltage Options Single Working Temperature -40~+60°C PDF Datasheet ELED-30-DP2_2022-04-14-094641.pdf

Read more less

Constant Voltage Design 12V or 24V Output Dimmable using leading edge & trailing edge Triac Dimmers PWM Output 3 Years warrantyMore Information Manufacturer Ecopac Power Output Wattage (W) 60 Dimmable (Type) Triac Leading edge & Trailing edge Dimensions 178x 61x 24 EMC Standards Compliance to EN55015, EN61000-3-2,3 (>60% load) Input Voltage 200-240VAC Safety Standards EN61347-1, EN61347-2-13 Working Temperature -40~+70°C PDF Datasheet ELED-60P-T.pdf

Read more less

Product family features Line frequency: 0 Hz | 50 Hz | 60 Hz Versatile DALI window driver up to 50 W due to flexible output characteristic Supply voltage: 220…240 V Available with output current range: up to 1,400 mA Constant Lumen Output (CLO) Integrated customizable thermal management (Driver Guard) Product family benefits Fully programmable via software (DALI Interface, NFC) Advanced luminaire/driver data (power, energy, operating hours…) for analytics DALI-2 certified incl. Parts 251, 252, 253 Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate) High-quality dimming of 1…100 % by amplitude dimming Higher quality of light thanks to < 3% output ripple current Very high efficiency Very low standby power consumption: < 0.15 W * Fulfill safety requirement due to overload, overtemperature, Hot Plug protection Areas of application Linear lighting for office, education, industry, storage areas and retail Installation in emergency lighting systems according to IEC 61347-2-13, appendix J Suitable for luminaires of protection class I Ecodesign regulation information: Intended for use with LED modules. The forward voltage of the LED light source shall be within the defined operating window of the control gear in all operating conditions including dimming if applicable. Separate control gear and light sources must be disposed of at certified disposal companies in accordance with Directive 2012/19/EU (WEEE) in the EU and with Waste Electrical and Electronic Equipment (WEEE) Regulations 2013 in the UK. For this purpose, collection points for recycling centres and take-back systems (CRSO) are available from retailers or private disposal companies, which accept separate control gear and light sources free of charge. In this way, raw materials are conserved and materials are recycled. Find technical data and additional assets in our datasheet Product Datasheet

Read more less

premium series Product description NEW: lumDATA (DALI-2 part ext. 251, 252 and 253) Dimmable built-in constant current LED Driver Dimming range 1 to 100 % For luminaires of protection class I and protection class II Output current adjustable between 500 – 1,400 mA Max. output power 45 W Up to 90 % efficiency Power input on stand-by < 0.15 W Nominal lifetime up to 100,000 h 5 years guarantee Housing properties Casing: polycarbonate, white Type of protection IP20 Interfaces one4all (DALI-2 DT 6, DSI, switchDIM, corridorFUNCTION) ready2mains (configuration and dimming via mains) Terminal blocks: 0° push terminals Functions Adjustable output current in 1-mA-steps (DALI, ready2mains, I-SELECT 2) Fulfills DALI-2 parts: 251 (Luminaire data), 252 (Energy reporting) and 253 (Diagnostics & Maintenance) Constant light output function (CLO) Power-up fading at AC Configurable via ready2mains Switch off the Driver with fade2zero Service monitor to log certain events Protective features (overtemperature, short-circuit, overload, no-load, input voltage range, reduced surge amplification) Suitable for emergency escape lighting systems acc. to EN 50172 Benefits Application-oriented operating window for maximum compatibility Best energy savings due to low stand-by losses and high efficiency Flexible configuration via DALI, ready2mains and I-SELECT 2 Reliability proven by lifetime up to 100,000 h and 5 years guarantee Typical applications For linear/area lighting in office applications

Read more less

The Ecopac Power ELED-50-24D DALI Dimmable LED driver is high quality with a dimming range from 0.1% up to 100%. Short circuit and over loading protection are standard features. This model is a constant current design with a 24 volt output. Ecopac Power LED Drivers are supplied with a 3 year warranty.  Other features: DALI Dimmable Dimming range: 0.1-100% Universal AC input/ Full range 100-265VAC Built-in active PFC function 24V Constant voltage output IP20 Rated 3 years warrantyMore Information Manufacturer Ecopac Power Output Wattage (W) 50 Output Voltage 24V Dimmable (Type) DALI DC Output Adjustment N/a EMC Standards EN55015, EN61000-3-2, EN61000-4-2,3,4,5,6,11 Input Voltage 100-265VAC Safety Standards EN61347-1,EN61347-2-13 Working Temperature -40~+60°C PDF Datasheet ELED-50-D Series-1.pdf

Read more less

obsolete the latest alternative and what you will be sent is this
