Digital Dimming Ballast to run 2 X 21/39w T5 tubes - PCA 2x21/39 T5 ECO - 22185102 Product description Processor-controlled ballast with xitec II inside Highest possible energy class CELMA EEI = A1 BAT (1) Noise-free precise control via DALI or DSI signal, switchDIM or corridorFUNCTION Nominal lifetime up to 100,000 h (at ta 50 °C with a failure rate ≤ 0.2 % per 1,000 h) Multilamp management OEM-specific reserved memory areas 5 years guarantee Interfaces DALI DSI switchDIM (with memory function + selectable dimming rate) corridorFUNCTION (3 preprogrammed profiles) Integrated SMART interface for function with SMART Sensor 5D 19f and corridorFUNCTION plugs Functions Intelligent Temperature Guard (overtemperature protection) Intelligent Voltage Guard (overvoltage indication and undervoltage shutdown) Optimum filament heating in any dimmer setting Disconnection of filament heating from a dimming level of approx. 90 % for maximum energy efficiency (SMART-Heating concept) corridorFUNCTION with ambient light control Automatically triggered emergency lighting value in DC mode, 15 % For emergency lighting systems as per EN 50172 Automatic start after replacement of defective lamps Automatic shutdown if the lamp is faulty

Read more less

Philips Electronic HF performer II TL-D ballast to run 2x 58w T8 Tubes @ 2 X 70W T8 tubes 2 x 55W PL-L Lamps   - HFP258TLDEII View Datasheet

Read more less

The Osram QTP-OPTIMAL 1x54-58 is a Multiwatt non dimmable high frequency ballast to run 1 X 55w PL-L, 54W T5 TUBE AND 58W T8 TUBE. Product family benefits Long lamp life No adverse effect from frequent on/off switching Automatic restart after lamp replacement Perfect lamp start for applications with motion sensors VDE/VDE EMC certified system Very high energy efficiency due to cut-off technology Areas of application Emergency lighting systems acc. to EN 50172 / DIN VDE 0108-100 Industry Open-plan offices, corridors and storage rooms Public buildings Sports halls and factories Strip lighting Suitable for emergency lighting (DC operation) Modernization of existing systems Suitable for luminaires of protection classes I and II Data Sheet Product Data Sheet

Read more less

ELP 24-49w HE T5 Ballast - ELP - OM52449/T5/TI

Read more less

Tridonic PC11824TCLPRO 1x18/24w PLL Ballast - PC1/18/24TLCPRO - 22176068

Read more less

Specifications General Information Remarks UK importer address: Signify Commercial UK Limited, 3, Guildford Business Park, GU2 8XG Application code EII Type version mk4 Lamp type PL-T/C/L/TL5C Number of lamps 2 piece/unit Number of products on MCB (16 A type B) (nom.) 12 Automatic restart Yes Operating and Electrical Input Voltage 220 to 240 V Input frequency 50 to 60 Hz Operating frequency (max.) - kHz Operating frequency (min.) 42 kHz Operating frequency (nom.) 45 kHz Ignition method Warm Start Crest factor (max.) 1.7 Power factor 100% load (nom.) 0.95 Ignition time (max.) 0.52 s Mains voltage performance (AC) -8%-+6% Mains voltage safety (AC) -10%-+10% Earth leakage current (nom.) 0.5 mA Inrush current width 0.35 ms Constant wattage deviation -2%/+2% Ballast factor (nom.) 1 Power losses (nom.) 4.35-4.93 W Inrush current peak (max.) 31 A Wiring Connector type input terminals Insert Cable capacity output wires mutual (nom.) 100 pF Connector type output terminals Insert Cable length hot-wiring 0.75 m Wire strip length 7.5-8.5 mm Dual fixture master/slave Not applicable  [ Master/Slave oper. not applicable] Input terminal cross section 0.50-1.50 mm² Output terminal cross section 0.50-1.50 mm² Cable capacity output wires to earth (nom.) 100 pF System characteristics Rated ballast-lamp power 22-42 W Rated lamp power on PL-T/C 22/42 W Temperature T-ambient (max.) 50 °C T-ambient (min.) -25 °C T storage (max.) 80 °C T storage (min.) -40 °C T-case lifetime (nom.) 75 °C T-Case maximum (max.) 75 °C T-Ignition (max.) 50 °C T-Ignition (min.) -25 °C Emergency Operation Battery voltage lamp ignition 198-254 V Battery voltage lamp operation 176-254 Approval and Application Energy efficiency index A2 IP classification IP 20  [ Ingress Protection 20] EMI 9 kHz ... 30 MHz EN55015 EMI 30 MHz ... 1,000 MHz EN55022 level B Safety standard IEC 61347-2-3 Performance standard IEC 60929 Quality standard ISO 9000:2000 Environmental standard ISO 14001 Harmonic current emission standard IEC 61000-3-2 EMC immunity standard IEC 61547 Vibration standard IEC68-2-6 F c Bumps standard IEC 68-2-29 Eb Humidity standard EN 61347-2-3 clause 11 Approval marks CE marking ENEC certificate VDE-EMV certificate Temperature marking Yes Emergency standard IEC 60598-2-22 Humming and noise level Inaudible Product Data Full product code 871150091399930 Order product name HF-P 2 22-42 PL-T/C/L/TL5C EII 220-240V EAN/UPC – product 8711500913999 Order code 91399930 Local code HFP22242PLT/C/L Numerator – quantity per pack 1 SAP numerator – packs per outer box 12 Material no. (12 NC) 913700630866 Net Weight (Piece) 0.150 kg Installation Diagrams HF-P 2 22-42 PL-T/C/L/TL5C EII 220-240 V

Read more less

2x36w Electronic Ballast 240v - Vossloh Schwabe - ELXE238.527 188137

Read more less

The Osram QTi DALI-T/E 1x18-57/220-240 DIM is a dali  ballast to run 1 x 18w, 26w, 32w, 42w or 57w triple turn compact fluorescent lamp. These ballasts have an average life of 100,000 hours, offer flicker free light, have an automatic safety shutdown at lamp failure, automatic restart after lamp replacement and are suitable for emergency lighting.

Read more less

1x21/39w T5 Excel Ballast - Tridonic - 22185110 - PCA12139T5 EXCEL

Read more less

Tridonic Combined Electronic ballast to run 1 x 28 - 33w Compact DD lamps - PC 1 x 28-33 DD Combo

Read more less

The Osram QTP-OPTIMAL 1x18-40 is a Multiwatt non dimmable high frequency ballast to run 1 x 18w, 24w, 36w, 40w PL-L, 18w & 24w DULUX F, 15w & 18w T8 tubes and 24w & 39w T5 lamps. Product family benefits Long lamp life No adverse effect from frequent on/off switching Automatic restart after lamp replacement Perfect lamp start for applications with motion sensors VDE/VDE EMC certified system Very high energy efficiency due to cut-off technology Areas of application Emergency lighting systems acc. to EN 50172 / DIN VDE 0108-100 Industry Open-plan offices, corridors and storage rooms Public buildings Sports halls and factories Strip lighting Suitable for emergency lighting (DC operation) Modernization of existing systems Suitable for luminaires of protection classes I and II Data Sheets Product Data Sheet

Read more less

Digital Dimming Ballast to run 4 X 14/24w T5 tubes - PCA 4x14/24 T5 ECO - 22176212

Read more less
