The Osram QTi DALI 2x18/220-240 DIM is a digital dimmable ballast to run 2 x 18w T8 Tubes. These ballasts have an average life of 100,000 hours, offer flicker free light, have an automatic safety shutdown at lamp failure, automatic restart after lamp replacement and are suitable for emergency lighting.

Read more less

Product family benefits System+ Guarantee available Easy integration in luminaire thanks to same dimensions like DALI GI ECG TouchDIM function for easy and inexpensive dimming of several ECGs Same luminous flux with direct and alternating current Dimming of amalgam lamps without flickering or reduced lifespan Automatic restart after lamp replacement DALI product features Control via the DALI interface Compliance with the DALI Version-1 and IEC 60929 Control input protected against overvoltage and polarity reversal (OSRAM ECG) Touch DIM and Touch DIM Sensor function Manual dimming without controller and with standard switches Including memory function (double click) and soft start Areas of application Suitable for use in emergency lighting systems as per EN 50172/DIN VDE 0108-100 Installation in emergency lighting systems according to IEC 61347-2-3, appendix J Industry Open-plan offices, corridors and storage rooms Public buildings Sports halls and factories Strip lighting Shop lighting Suitable for luminaires of protection class I References / LinksFor more information on the system guarantee and the terms and conditions of the guarantee visit www.osram.com/system-guarantee Data sheet More downloads Technical Data Electrical data Input voltage AC 198…264 V Nominal voltage 220…240 V Mains frequency 50…60 Hz Input voltage DC 154…276 V Maximum output power 54 W Efficiency in full-load 92 % Operating frequency 44…120 kHz Max. ECG no. on circuit breaker 10 A (B) 17 Max. ECG no. on circuit breaker 16 A (B) 28 Inrush current 24 A Light technical data Starting time 0.6 s Dimensions & weight Length 360.0 mm Width 30.0 mm Height 21.0 mm Mounting hole spacing, length 350.0 mm Product weight 270.00 g Cable cross-section, output side 0.5…1.5 / 0.5…1.0 mm² Cable cross-section, input side 0.5…1.5 / 0.5…1.0 mm² Temperatures & operating conditions Ambient temperature range +10…+50 °C Permitted rel. humidity during operation 5…85 % Lifespan ECG lifetime 100000 h Additional product data Suitable for lamp power (1 lamp) 28…54 W Capabilities Dimming interface DALI / Touch DIM / Touch DIM Sensor Dimming range 1…100 % Dimmable Yes Overheating protection Power reduction and switch off at T > 75 °C at the tc point Suitable for fixtures with prot. class I End of lamp life safety shutdown EOL T.2 Intended for no-load operation No Max. cable length to lamp/LED module 1.0 m / 1.5 m Certificates & standards Approval marks – approval VDE / VDE-EMC / EL / EAC / RCM / CCC Standards Acc. to EN 55015; EN 55022/Acc. to EN 61547/Acc. to IEC 61000-3-2/EN 61000-3-2/Acc. to EN 61347-2-3/Acc. to EN 60929/Acc. to EN 55015:2006 + A1:2007/Acc. to EN 61000-3-2/Acc. to EN 61547/Acc. to IEC 62386-101:Ed1/Acc. to IEC 62386-102:Ed1 Protection class I Type of protection IP20 EEI – Energy Label A1 BAT Logistical data Commodity code 850410809000 Environmental information Information according Art. 33 of EU Regulation (EC) 1907/2006 (REACh) Date of Declaration 14-04-2022 Primary Article Identifier 4050300870809 Candidate List Substance 1 Lead CAS No. of substance 1 7439-92-1 Safe Use Instruction The identification of the Candidate List substance is sufficient to allow safe use of the article. Declaration No. in SCIP database e3bb252d-4962-4b8e-bccd-cfc5cb474662 Packaging information EAN Unit Piece Dimension l x w x h Weight Volume 4050300870809 UNV  1 360mm x 30mm x 21mm 270.00g 0.23dm³ 4050300870816 VS  20 392mm x 98mm x 165mm 5579.99g 6.34dm³

Read more less

OBSOLETE , IF using DALI dimming the below will suffice   DALI Alternative   If using DSI no alternative available    Tridonic Electronic compact dimming ballast to run 1 x 26-57w TC Compact The Tridonic PCA 1x26-57 TC ECO xitec II is a high frequency dimmable ballast for use with DALI/DSI/switchDIM interfaces. Compatible with the following lamps: 1 x 40w T5 Circular Lamp 1 x 26w Double Turn Compact Fluorescent Lamp 1  x 26w Triple Turn Compact Fluorescent Lamp 1 x 40w Long Single Turn Compact Fluorescent Lamp 1 x 40w T5 Circular Fluorescent Lamp 1 x 32w Triple Compact Fluorescent Lamp 1 x 42w Triple Turn Compact Fluorescent Lamp 1 x 57w Triple Turn Compact Fluorescent Lamp Tridonic part number: 22185120

Read more less

35W/55w SOX Ballast Integral Ignitor CA8MFD capacitor if using 35W  CA6MFD Capacitor if using 55W  159mm x 50mm x 67mm

Read more less

This item is no longer available , If order you will be sent a  smaller alternative   Technical Specifications Wattage 16 W Manufacturer Vossloh Schwabe Dimming? Non-Dimmable Compact 16 watt Height 28 mm Length 130 mm Type Control Gear Width 28 mm

Read more less

Tridonic PC236TCLPRO Electronic Ballast 220/240v 50/60/0Hz to run 2x36w PLL Tubes - PC 2/36 TCL PRO

Read more less

Tridonic PC155TCLPRO Electronic Ballast to run 1x55w PLL lamp - PC 1/55 TCL PRO - 22088432

Read more less

150w Powertronic Ballast - Osram - PTU150 - PTI150S

Read more less

Tridonic PC154T5PRO Electronic HF low profile Ballast to run 1 x 54w T5 Tubes - PC 1/54 T5 PRO LP

Read more less

1x4-16ww T4/T5 High Fequency Ballast - Osram - QTECO1x16/220-240 - QTE14L

Read more less

TCI BCC/SL - Linear mini electronic ballast 1x 10W Product Code: BCC 116 SL* T5 4-6-8-13-14W T8 16W PLS 5/7/9/11W PLC 10W 2D 10-16W DATA SHEET Description- Compact size electronic ballast for built-in use - Suitable for connection to emergency equipment in compliance with EN-60598-2-22 - Can be used for lighting equipment in protection Class l and ll - Push in connector with retaining springs. Connector cross section 0.5 - 1.5 mm2 - Start with pre-heating for longer lamp life (cut-off function) - Protection against lamp disconnection (re-start with pre-heating), lamp failure or end of life - Ballast can be secured with slots for M4 screws Specification Lamp TC-D/E Cap G24q-1 Power (W) 10 Length (mm) 150 Width (mm) 22 Height (mm) 19

Read more less

400w HID Ballast for mercury based metal halides  or Dual lamps
