APV-16-12 - Mean Well LED Driver APV-16-12 15W 12V

Description

Constant Voltage Fully isolated plastic case Protections: Short circuit/ Overload/ Over voltage Other features: Universal AC input / Full Range Small and compact size Isolation class II, no FG Cooling by free air convection Pass LPS 100% full load burn-in test Low cost, High reliability 2 years warranty
More Information Manufacturer Mean Well Output Wattage (W) 15 Output Voltage 12V Dimmable (Type) No DC Output Adjustment N/A Dimensions 77 x 40 x 29 EMC Standards EN55015, EN61000-3-2 class A, EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11, EN61547 Input Voltage 90~264VAC; 127~370VDC Safety Standards Design refer to TUV EN60950-1, EN61347-2-13, UL8750 Output Voltage Options Single Working Temperature -30°C~+70°C (Refer to "Derating Curve") PDF Datasheet APV-16-5_20spec_1__1.pdf

APV-16-12 - Mean Well LED Driver APV-16-12 15W 12V

Product form

SKU: APV-16-12

Trade price available - contact us

£9.24 Excl. VAT

(inc. 20% VAT): £11.09

    • Contact us to confirm availability

    Description

    Constant Voltage Fully isolated plastic case Protections: Short circuit/ Overload/ Over voltage Other features: Universal AC input / Full Range Small and compact size Isolation class II, no FG Cooling by free air convection Pass LPS 100% full load burn-in test Low cost, High reliability 2 years warranty
    More Information Manufacturer Mean Well Output Wattage (W) 15 Output Voltage 12V Dimmable (Type) No DC Output Adjustment N/A Dimensions 77 x 40 x 29 EMC Standards EN55015, EN61000-3-2 class A, EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11, EN61547 Input Voltage 90~264VAC; 127~370VDC Safety Standards Design refer to TUV EN60950-1, EN61347-2-13, UL8750 Output Voltage Options Single Working Temperature -30°C~+70°C (Refer to "Derating Curve") PDF Datasheet APV-16-5_20spec_1__1.pdf
