66205100 Specifications General Information Remarks UK importer address: Signify Commercial UK Limited, 3, Guildford Business Park, GU2 8XG Application code E+ Type version mk2 Lamp type TL5 Number of lamps 1 piece/unit Number of products on MCB (16 A type B) (nom.) 39 Automatic restart Yes Operating and Electrical Input Voltage 195-240 V Input frequency 50 to 60 Hz Operating frequency (max.) 110 kHz Operating frequency (min.) 45 kHz Ignition method Warm Start Crest factor (max.) 1.7 Power factor 100% load (nom.) 0.95 Ignition time (max.) 1 s Mains voltage performance (AC) -8%-+6% Mains voltage safety (AC) -10%-+10% Earth leakage current (max.) 0.5 mA Inrush current width 0.18 ms Standby power consumption (max.) 0.25 W Ballast factor (nom.) 1 Power losses (nom.) 3.8 W Inrush current peak (max.) 20 A Wiring Connector type input terminals WAGO 251 universal connector  [ Suitable for both automatic wiring (ALF and ADS) and manual wiring] Cable capacity output wires mutual (max.) 200 pF Connector type output terminals WAGO 251 universal connector  [ Suitable for both automatic wiring (ALF and ADS) and manual wiring] Connector type control input terminals WAGO 251 universal connector  [ Suitable for both automatic wiring (ALF and ADS) and manual wiring] Wire strip length 8.0-9.0 mm Dual fixture master/slave Yes  [ Master/Slave operation possible] Control input terminal cross section 0.50-1.00 mm² Input terminal cross section 0.50-1.00 mm² Output terminal cross section 0.50-1.00 mm² Auto-insert (ALF/ADS) wire cross section 0.75 mm² Cable capacity output wires to earth (max.) 200 pF System characteristics Rated ballast-lamp power 28-35-49-54 W Rated lamp power on TL-D 58 W System power on TL-D 55.5 W Lamp power on TL-D 52.2 W Power loss on TL-D 3.3 W Rated lamp power on PL-L 55 W System power on PL-L 54.6 W Lamp power on PL-L 51.2 W Power loss on PL-L 3.4 W Rated lamp power on TL5 28/35/49/54 W System power on TL5 32.1/39.1/55.1/57.7 W Lamp power on TL5 29.4/36.4/51.6/54.8 W Power loss on TL5 2.7/3.0/3.5 W Rated lamp power on TL5 ECO 25/32/45/50 W System power on TL5 ECO 29.4/33.1/49.1/54.2/ W Lamp Power on TL5 ECO 26.3/30.2/45.7/50.4 W Rated lamp power on TL-D ECO 51 W System power on TL-D ECO 45.8 W Power loss on TL-D ECO 3.1 W Lamp power on TL-D ECO 42.7 W Power loss on TL5 ECO 3.1/2.9/3.4/3.8/ W Temperature T-ambient (max.) 50 °C T-ambient (min.) -25 °C T storage (max.) 80 °C T storage (min.) -40 °C T case lifetime (max.) 75 °C T-Case maximum (max.) 75 °C Stable lamp operation temperature 15°C T-Ignition (max.) 50 °C T-Ignition (min.) -25 °C Controls and Dimming Control interface TD Regulating level power 1%-100% Control input protection Yes (Basic insulation) Mechanical and Housing Housing L 359x30x21 Emergency Operation Battery voltage lamp ignition 198-254 V Battery voltage lamp operation 176-254 Approval and Application Energy efficiency index A1 BAT IP classification IP 20  [ Ingress Protection 20] EMI 9 kHz ... 30 MHz EN55015 EMI 30 MHz ... 1,000 MHz EN 55022 Class B Safety standard IEC 61347-2-3 Performance standard IEC 60929 Quality standard ISO 9000:2000 Environmental standard ISO 14001 Harmonic current emission standard IEC 61000-3-2 EMC immunity standard IEC 61547 Vibration standard IEC68-2-6 F c Bumps standard IEC 68-2-29 Eb Humidity standard EN 61347-2-3 clause 11 Approval marks CE marking ENEC certificate VDE-EMV certificate Temperature marking Yes Emergency standard IEC 60598-2-22 Humming and noise level Inaudible Product Data Full product code 871829166205100 Order product name HF-Ri TD 1 28/35/49/54 TL5 E+ 195-240V EAN/UPC – product 8718291662051 Order code 66205100 Local order code HFRITD12854T5PL SAP numerator – quantity per pack 1 Numerator – packs per outer box 12 SAP material 913700695666 SAP net weight (piece) 0.261 kg

Read more less

PureVOLT IUV-2S60-M4-LD This Philips electronic ballast runs the following lamps : Philips TUV 55W HO G55T8 Philips TUV 75W HO G75T8 Philips TUV PL-L 35W HO/4P Philips TUV PL-L 60W HO/4P Philips TUV PL-L 95W HO/4P Philips TUV 36 T5 HO 75W 4P-SE Detailed product description Advance Pure Volt IUV-2S60-M4-L The microprocessor controlled Advance PureVOLT electronic ballasts are specifically designed to operate a variety of germicidal lamps. PureVOLT ballasts operate the following low pressure mercury germicidal UV lamps:High OutputTwin Tube: (1 or 2) HO 35W or 60W; (1) HO 95WLinear: (1 or 2) 36T5HO (75W); (1) 64T5HO (145W) Standard OutputTwin Tube: (1 or 2) TUV 18 PL-L or 36 PL-L The Advance PureVOLT ballasts for UV lamps offer exclusive features such as IntelliVolt® technology (allowing the ballast to operate at any input voltage from 120 to 277 volts, 50/60 Hz), dual entry, color-coded connectors and lamp EOL protection.A powerful pair, the combination of germicidal lamps with an Advance PureVOLT ballast provides the appropriate level of UV-C energy to stop the spread of microorganisms, airborne contaminants, and pathogens, reducing the threat of illness andhelping to ensure a safer environment for building occupants. Other options TUV 55W HOTUV 75W HOTL 60W/10TL 80W/10 Product parameters Drivers for TUV Manufacturer Philips EAN 8727900783995 Product number 914499999001 Source type IUV-2S60-M4-LD Number of sources 1 or 2 Type UIV-2S60-M4-LD GPC code 914499999001 EOC code 872790078399500 Pieces in box 20ks Voltage 120-277 V Current 0,56 - 1,3 A Length 175 mm Height 34 mm Width 77 mm IP protection IP20 Dimmable No

Read more less

Philips Electronic HF performer II TL-D ballast to run 1x58w or 1 x70W T8 Tubes - HFP158TLDEII Specifications General information Application Code III Type Version IDC Lamp Type TL-D/PL-L Number of Lamps 1 piece/unit Number of Products on MCB (16A Type B) (Nom) 28 Automatic Restart Yes Operating and electrical Input Voltage 220 to 240 V Input Frequency 50 to 60 Hz Operating Frequency (Nom) 45 kHz Ignition Method Programmed Start Crestfactor (Max) 1.7 Power Factor 100% Load (Nom) 0.99 Ignition Time (Max) 0.9 s Mains Voltage Performance (AC) -8%-+6% Mains Voltage Safety (AC) -10%-+10% Earth Leakage Current (Nom) 0.5 mA Inrush Current Width 0.25 ms Constant Wattage Deviation -2%/+2% Ballast Factor (Nom) 0.95 Power Factor (Nom) 0.99 Power Losses (Nom) 4.3-4.4 W Inrush Current Peak (Max) 18 A Efficiency at full load [%] 93.3 % Wiring Connector Type Input Terminals WAGO 251 universal connector  [ Suitable for both automatic wiring (ALF and ADS) and manual wiring] Cable Capacity Output Wires Mutual (Nom) 200 pF Connector Type Output Terminals WAGO 251 universal connector  [ Suitable for both automatic wiring (ALF and ADS) and manual wiring] Cable Length Hot Wiring 0.75 m Wire Striplength 8.0-9.0 mm Dual Fixture Master/Slave Not applicable  [ Master/Slave oper. not applicable] Input Terminal Cross Section 0.50-1.00 mm² Output Terminal Cross Section 0.50-1.00 mm² Cable Capacity Output Wires to Earth (Nom) 200 pF System characteristics Rated Ballast-Lamp Power 58 W Rated Lamp Power on TL-D 58 W System Power on TL-D 56.3W@58W; 63.8W@70 W Lamp Power on TL-D 51.9W@58W; 59.6W@70 W Power Loss on TL-D 4.4W@58W; 4.3W@70 W System Power on PL-L 55.8W@55 W Lamp Power on PL-L 51.5W@55 W Power Loss on PL-L 4.3W@55 W Temperature T-Ambient (Max) 60 °C T-Ambient (Min) -25 °C T-Storage (Max) 50 °C T-Storage (Min) -40 °C T-Case Lifetime (Nom) 80 °C T-Case Maximum (Max) 80 °C T-Ignition (Max) 60 °C T-Ignition (Min) -25 °C Mechanical and housing Housing L 280x30x28 Emergency operation Nominal Light Output After 60 Seconds 100% of EBLF Battery Voltage Lamp Ignition 186-275 V Normal Operating Voltage (DC) 220-240 V Battery Voltage Lamp Operation 186-275 Battery Voltage Guaranteed Operation 176-275 V Battery Voltage Guaranteed Ignition 186-275 V Emergency Ballast Lumen Factor (EBLF) (Nom) 100 % Nominal Light Output After 5 Seconds 50% of EBLF Approval and application Energy Efficiency Index A2 BAT IP Classification IP 20  [ Ingress Protection 20] EMI 9 kHz ... 30 MHz EN55015 EMI 30 MHz ... 1000 MHz EN55022 level B Safety Standard IEC 61347-2-3 Performance Standard IEC 60929 Quality Standard ISO 9000:2000 Environmental Standard ISO 14001 Harmonic Current Emission Standard IEC 61000-3-2 EMC Immunity Standard IEC 61547 Vibration Standard IEC68-2-6 F c Bumps Standard IEC 68-2-29 Eb Humidity Standard EN 61347-2-3 clause 11 Approval Marks CE marking ENEC certificate VDE-EMV certificate Temperature Marking Yes Emergency Standard IEC 60598-2-22 Hum And Noise Level < 30 dB(A) Product data Full product code 872790091170100 Order product name HF-P 158 TL-D III 220-240V 50/60Hz IDC EAN/UPC - Product 8711500999702 Order code 913713031866 Numerator - Quantity Per Pack 1 Numerator - Packs per outer box 12 Material Nr. (12NC) 913713031866 Net Weight (Piece) 0.205 kg Installation diagrams HF-P 158 TL-D III 220-240V 50/60Hz IDC HF-P 158 TL-D III 220-240 V 50/60 Hz IDC

Read more less

66205100 Specifications General Information Remarks UK importer address: Signify Commercial UK Limited, 3, Guildford Business Park, GU2 8XG Application code E+ Type version mk2 Lamp type TL5 Number of lamps 1 piece/unit Number of products on MCB (16 A type B) (nom.) 39 Automatic restart Yes Operating and Electrical Input Voltage 195-240 V Input frequency 50 to 60 Hz Operating frequency (max.) 110 kHz Operating frequency (min.) 45 kHz Ignition method Warm Start Crest factor (max.) 1.7 Power factor 100% load (nom.) 0.95 Ignition time (max.) 1 s Mains voltage performance (AC) -8%-+6% Mains voltage safety (AC) -10%-+10% Earth leakage current (max.) 0.5 mA Inrush current width 0.18 ms Standby power consumption (max.) 0.25 W Ballast factor (nom.) 1 Power losses (nom.) 3.8 W Inrush current peak (max.) 20 A Wiring Connector type input terminals WAGO 251 universal connector  [ Suitable for both automatic wiring (ALF and ADS) and manual wiring] Cable capacity output wires mutual (max.) 200 pF Connector type output terminals WAGO 251 universal connector  [ Suitable for both automatic wiring (ALF and ADS) and manual wiring] Connector type control input terminals WAGO 251 universal connector  [ Suitable for both automatic wiring (ALF and ADS) and manual wiring] Wire strip length 8.0-9.0 mm Dual fixture master/slave Yes  [ Master/Slave operation possible] Control input terminal cross section 0.50-1.00 mm² Input terminal cross section 0.50-1.00 mm² Output terminal cross section 0.50-1.00 mm² Auto-insert (ALF/ADS) wire cross section 0.75 mm² Cable capacity output wires to earth (max.) 200 pF System characteristics Rated ballast-lamp power 28-35-49-54 W Rated lamp power on TL-D 58 W System power on TL-D 55.5 W Lamp power on TL-D 52.2 W Power loss on TL-D 3.3 W Rated lamp power on PL-L 55 W System power on PL-L 54.6 W Lamp power on PL-L 51.2 W Power loss on PL-L 3.4 W Rated lamp power on TL5 28/35/49/54 W System power on TL5 32.1/39.1/55.1/57.7 W Lamp power on TL5 29.4/36.4/51.6/54.8 W Power loss on TL5 2.7/3.0/3.5 W Rated lamp power on TL5 ECO 25/32/45/50 W System power on TL5 ECO 29.4/33.1/49.1/54.2/ W Lamp Power on TL5 ECO 26.3/30.2/45.7/50.4 W Rated lamp power on TL-D ECO 51 W System power on TL-D ECO 45.8 W Power loss on TL-D ECO 3.1 W Lamp power on TL-D ECO 42.7 W Power loss on TL5 ECO 3.1/2.9/3.4/3.8/ W Temperature T-ambient (max.) 50 °C T-ambient (min.) -25 °C T storage (max.) 80 °C T storage (min.) -40 °C T case lifetime (max.) 75 °C T-Case maximum (max.) 75 °C Stable lamp operation temperature 15°C T-Ignition (max.) 50 °C T-Ignition (min.) -25 °C Controls and Dimming Control interface TD Regulating level power 1%-100% Control input protection Yes (Basic insulation) Mechanical and Housing Housing L 359x30x21 Emergency Operation Battery voltage lamp ignition 198-254 V Battery voltage lamp operation 176-254 Approval and Application Energy efficiency index A1 BAT IP classification IP 20  [ Ingress Protection 20] EMI 9 kHz ... 30 MHz EN55015 EMI 30 MHz ... 1,000 MHz EN 55022 Class B Safety standard IEC 61347-2-3 Performance standard IEC 60929 Quality standard ISO 9000:2000 Environmental standard ISO 14001 Harmonic current emission standard IEC 61000-3-2 EMC immunity standard IEC 61547 Vibration standard IEC68-2-6 F c Bumps standard IEC 68-2-29 Eb Humidity standard EN 61347-2-3 clause 11 Approval marks CE marking ENEC certificate VDE-EMV certificate Temperature marking Yes Emergency standard IEC 60598-2-22 Humming and noise level Inaudible Product Data Full product code 871829166205100 Order product name HF-Ri TD 1 28/35/49/54 TL5 E+ 195-240V EAN/UPC – product 8718291662051 Order code 66205100 Local order code HFRITD12854T5PL SAP numerator – quantity per pack 1 Numerator – packs per outer box 12 SAP material 913700695666 SAP net weight (piece) 0.261 kg

Read more less

1 x TUV36T5HO - TUV60WPLL - TUV55WHO - TUV75WHO - GXO36T6PH Lightwave UV Ballast - EB-1006-02LF (LW20EB65-G01S). This ballast has switch for 120 volt or 220/230 volt.  Operates one germicidal lamp, Max Lamp Wattage: 75 watts, Lamp Voltage Range: 110-179 v, Lamp Current Range: 600-800 mA.  Lamp type - GHO36, GXO36T6PH, TUV 55, 65, 75 W (PLL).   Rapid start. Dimensions - Length (includes mounting tabs) 4.25" ,  Width - 2.25",  Height 1.25".    * No Wires, plug in wire ports, Case Size D.  Model # EB-1006-02LF, Lightwave.

Read more less

No Capacitor or Ignitor required with this ballast as built in  This item is now obsolete , we do however still have the RSF355245 exactly the same functionality just a different shape  . Please see   Alternative  , this is what you will be sent if you order the RSD355245  Magnetic Ballast Electrical Data Lamp Watts (W) 35 55 Lamp Current (A) 0.6 0.59 Input Voltage at 50Hz 240 240 Circuit Watts (W) 50 69 Running Current (A) 0.23 0.32 Delta T (°C) 50TA 50TA Thermal Cut-out N Capacitor Value (µf) 8 6 Capacitor Voltage (V) 250 250 Physical Data Dimensions (LxWxH mm) 144x65x51 Fixings (mm) 130 Weight (kg) 1.3 Please note this ballast does not require an ignitor

Read more less

Please note this item is now obsolete , you will be sent a Philips alternative which is exactly the  same size with the same terminals  This is the Tridonic PC 2/58 T8 Pro, a non-dimmable high frequency ballast to run 2 x 58w T8 fluorescent tube or 2 x 55w TC-L lamp.These ballasts have a nominal life time of up to 100,000 hours and provide a constant luminous flux even with fluctuations in mains voltage.Tridonic T8 Pro ballasts also have an automatic start after replacement of defective lamps and a safety shutdown of defective lamps at the end of a lamps life.

Read more less

Linear Electronic Ballast T8 1-2x58W, T5 1-2x54W, TC-L 1-2x55W Product Details Multi Watt High Frequency Ballast ELT high frequency ballast, Class I for built-in use. This multipower electronic ballast Operates two T8 lamps. Class I for built in useIgnition with pre-heating in cathodes for long lamp life without flashes and flickeringConstant total power and stabilized luminous fluxHigh frequency operation and high energy efficiencyCorrected stroboscopic effectAllows the use of Class I and Class II luminairesPermitted input voltage 198-264V, 50-60HzWithstands 2 hours at 350V acRapid connection with fixing spring

Read more less

This item is now obsolete  an alternative will be sent  This Osram QT-ECO 1x18-24/220-240 S is a non dimmable matchbox ballast to run: 1 x 24w T5 fluorescent tube 1 x 22w T5 Circular tube 1 x 15w or 18w T8 Fluorescent tube 1 x18w or 24w Double turn CFL's 1 x 18w or 24w DuluxW  F CFL's

Read more less

Digital Dimming Ballast to run 1 X 35/49/80w T5 tubes - PCA 1x35/80 T5 ECO - 22185096

Read more less

Digital Dimming Ballast to run 2 X 21/39w T5 tubes - PCA 2x21/39 T5 ECO - 22185102 Product description Processor-controlled ballast with xitec II inside Highest possible energy class CELMA EEI = A1 BAT (1) Noise-free precise control via DALI or DSI signal, switchDIM or corridorFUNCTION Nominal lifetime up to 100,000 h (at ta 50 °C with a failure rate ≤ 0.2 % per 1,000 h) Multilamp management OEM-specific reserved memory areas 5 years guarantee Interfaces DALI DSI switchDIM (with memory function + selectable dimming rate) corridorFUNCTION (3 preprogrammed profiles) Integrated SMART interface for function with SMART Sensor 5D 19f and corridorFUNCTION plugs Functions Intelligent Temperature Guard (overtemperature protection) Intelligent Voltage Guard (overvoltage indication and undervoltage shutdown) Optimum filament heating in any dimmer setting Disconnection of filament heating from a dimming level of approx. 90 % for maximum energy efficiency (SMART-Heating concept) corridorFUNCTION with ambient light control Automatically triggered emergency lighting value in DC mode, 15 % For emergency lighting systems as per EN 50172 Automatic start after replacement of defective lamps Automatic shutdown if the lamp is faulty

Read more less

Obsolete, If you are using the dali dimming feature please order the EL2X80IDIM , please note this is dali dimming only and not DSI dimming  Product description Processor-controlled ballast with xitec II inside Highest possible energy class CELMA EEI = A1 BAT (1) Noise-free precise control via DALI or DSI signal, switchDIM or corridorFUNCTION Nominal lifetime up to 100,000 h (at ta 50 °C with a failure rate ≤ 0.2 % per 1,000 h) Multilamp management OEM-specific reserved memory areas 5 years guarantee Interfaces DALI DSI switchDIM (with memory function + selectable dimming rate) corridorFUNCTION (3 preprogrammed profiles) Integrated SMART interface for function with SMART Sensor 5D 19f and corridorFUNCTION plugs Functions Intelligent Temperature Guard (overtemperature protection) Intelligent Voltage Guard (overvoltage indication and undervoltage shutdown) Optimum filament heating in any dimmer setting Disconnection of filament heating from a dimming level of approx. 90 % for maximum energy efficiency (SMART-Heating concept) corridorFUNCTION with ambient light control Automatically triggered emergency lighting value in DC mode, 15 % For emergency lighting systems as per EN 50172 Automatic start after replacement of defective lamps Automatic shutdown if the lamp is faulty

Read more less
